COUGARTRON MK300 Laser Marking Machine
Price range: €5,067.60 through €5,990.10 Inc Vat
The MK300 Laser marking machine offers the best electro-optical conversion rate and features the world’s most advanced laser generator. This machine stands out with its robust construction, stable power output,
efficient air cooling system, and design.
The MK300 has a fiber bundle with ytterbium, pumped by LEDs. The laser light goes to the optical head, which includes a beam expander, collimating optics, and back reflection protection.
High-performance laser marking machine delivers high precision results at speeds up to 7000mm/s.
Capable of marking text, numbers, QR codes, dates, graphics, and more. Its low-noise design makes it suitable for a variety of settings.
Easy to use with a portable design, it’s simple to carry and move. The integrated touchscreen software makes it easy to find your settings, offering advanced yet user-friendly operation.
Reliable and durable, the laser module boasts a working life of 50 000- 100 000 hours, ensuring consistent performance.
For safety, the machine includes an air cooling system and a handheld head with an integrated dark acrylic cover to protect your eyes, although the operator must use safety glasses.
See the user manual regarding safety when working with the MK300.
Main benefits:
- Advanced JPT laser generator for high-marking quality
- Galvo scanner increases speed by 20%
- Quiet operation with low noise
- Optional battery for flexibility
- Portable and easy to move
- Low power consumption saves energy
Materials the MK300 can mark on:
- All metals and alloys (iron, copper, aluminum, magnesium, zinc, etc.)
- Rare metals and alloys (gold, silver, titanium, etc.)
- All types of metal oxides
- Specially treated surfaces (anodized aluminum, phosphating, electroplating, etc.)
- Material coated surfaces
FEATURES AND SPECIFICATIONS
Laser type – Marking laser
Power output – 30W
Standard marking area – 100mm x 100mm
Laser handle part weight – 1.2kg
Marking speed – ≤7000mm/s
Repeated precision – 0.01mm
Wave length – 1064±10nm
Frequency of pulse – 20-100KHZ
Marking depth – ≤0.25mm (depends on material)
Mini line width – 0.03mm
Mini line characters – 0.2mm
Power supply – AC220V±10% 50Hz or AC110V±10% 60Hz
Cooling – Air cooling
Operation temperature – 10-45°C
Laser generator life – 50000 ~ 100000 hours
Software – Integrated Touch Screen Software
Machine weight – 15kg
| Type |
Battery powered 220V ,Corded 220V |
|---|
